Our Sheet Metal Fabrication For Various Applications
With custom sheet metal, TOPS accommodates a variety of industry needs.
Obtain A Free Quote For Custom Sheet Metal Prototypes And Small-Scale Production Components. Expect Precision Quality With A 3-Day Turnaround.
Choose TOPS sheet metal fabrication services for the creation of custom sheet metal parts, ranging from complex, low-volume prototypes to large, high-volume production runs. Select from a wide variety of materials and fabrication methods. Our local sheet metal fabricators and a team of experienced engineers guarantee that each component is crafted to precise specifications and quality standards.
Explore custom flat and formed sheet metal prototypes and production parts, from sturdy brackets to intricate panels, all crafted with precision to meet the varied needs of different industries.
TOPS provides accurate sheet metal prototyping and production, ideal for one-offs, small batches, and high volumes.
With an established clientele, we understand our customers choose us for various reasons, including our extensive network capacity, complimentary consultation, guaranteed quality, industry experience, and crucially, creating an economy of scale. Contact us today and submit your design file to request a free quote.
Aluminum with its lightweight yet robust nature, offers enhanced durability without excess weight. Its superior malleability allows precise shaping, ideal for intricate designs.
AL5052
AL5083
AL6061
AL6063
Copper’s advantages are clear: unparalleled electrical conductivity, thermal efficiency, and natural resistance to corrosion, ensuring longevity and performance in fabrications.
CU1020
CU1100
CU2100
CU2200
CU2300
CU2400
CU2600
Opt for brass to ensure precise machining, a distinct appearance, and efficient heat conductivity, providing advantages for both practical and decorative applications.
C27400
C28000
With its robustness, versatility, and recyclability, steel is an excellent material choice, ensuring long-lasting performance and environmental sustainability.
Cold Rolled Steel Plate (SPCC)
Hot Rolled Steel Plate (SPHC)
Electrolytic Plate (SECC)
Galvanized Plate (SGCC)
Renowned for its durability and resistance to staining, stainless steel ensures longevity and maintains its appearance, even in harsh environments.
301
303
304
316
420
430
Choose from our range of sheet metal finishes to improve corrosion resistance, durability, and aesthetic appeal. For finishes not listed on our quote page, simply select 'Other' and detail your requirements for a customized solution.
Tolerance Lever | Overall Dimension Range | ||||||
Specifications | <<3, >0.5 | <<6, >3 | <<30, >6 | <<120, >30 | <<400, >120 | <<1000, >400 | <<2000, >1000 |
Tolerance Standard | |||||||
F | ±0.05 | ±0.05 | ±0.1 | ±0.15 | ±0.2 | ±0.3 | ±0.5 |
M | ±0.1 | ±0.1 | ±0.2 | ±10.3 | ±0.5 | ±0.8 | ±1.2 |
C | ±0.2 | ±0.3 | ±0.5 | ±0.8 | ±1.2 | ±2 | ±3 |
V | – | ±0.5 | ±1 | ±1.5 | ±2.5 | ±4 | ±6 |
Explore the unique benefits of each sheet metal technique and find the ideal match when ordering custom metal fabrication parts.
Process | Techniques | Precision | Applications | Material Thickness (MT) | Lead Time |
Cutting |
Laser cutting, Plasma cutting | +/- 0.1mm | Stock material cutting Cutting of external shapes Secondary cutting Cutting lines Cutting irregular holes | 6 mm (¼ inch) or less | 1-2 days |
Bending | Bending | Single bend: +/- 0.1mm Double bend: +/- 0.2mm More than two bends: +/- 0.3mm | Forming, pressing lines, imprinting characters, riveting of electrostatic guide rails, pressing grounding symbols, hole punching, pressing flat, pressing triangular reinforcements, and more. | The smallest bend radius should be at least equal to the sheet thickness. | 1-2 days |
Welding | Tig Welding, MIG welding, MAG welding, CO2 welding | +/- 0.2mm | For aircraft fuselages and engine components. In car bodies, exhaust systems, and chassis. In creating components for power generation and distribution systems. | As low as 0.6 mm | 1-2 days |
Discover the distinct advantages of each sheet metal technique to find the perfect match when ordering custom metal fabrication parts.
Dimension Detail | Metric Units | Imperial Units |
Edge to edge, single surface | +/- 0.127 mm | +/- 0.005 in. |
Edge to hole, single surface | +/- 0.127 mm | +/- 0.005 in. |
Hole to hole, single surface | +/- 0.127 mm | +/- 0.005 in. |
Bend to edge / hole, single surface | +/- 0.254 mm | +/- 0.010 in. |
Edge to feature, multiple surface | +/- 0.762 mm | +/- 0.030 in. |
Over formed part, multiple surface | +/- 0.762 mm | +/- 0.030 in. |
Bend angle | +/- 1° |
By default, sharp edges will be smoothed and deburred. If any critical edges need to remain sharp, please indicate and specify them in your drawing.
With custom sheet metal, TOPS accommodates a variety of industry needs.
Sheet metal fabrication, a crucial process in manufacturing, involves forming thin metal sheets into metal components. This method is highly prized for its precision and durability, producing vital items like enclosures, brackets, and chassis. Suitable for various industries, it guarantees top-quality, dependable end-use products. Highlighting its significance in advanced engineering solutions, TOPS industrial sheet metal services excel at converting metal into indispensable, high-performance parts.
Sheet metal fabrication is an ideal method for both prototyping and mass production of metal components.
Sheet metal's versatility is evident in a wide range of applications, catering to both high-volume and specialized, low-volume requirements. Commonly fabricated metal parts include:
